Specification
Body size :230x200x240cm LxWxH
Inside size:210x188x195cm LxWxH
Towbar length:120cm
GTM:950kg
ATM:550kg
Tare Mass:400kg
Chassis:Galvanized steel pipe 3x5cm
Frame:Galvanized steel pipe 3x3cm
Thermal insulation:Cotton 3cm
Axles:Hunterman（default），AL-KO Brand(optional)
Tyres:165R13
Wheel hub:Chrome plated wheel hub
Brakes:Disc brake
Shock absorption :5 springs
Floor: Wood board+Non -slip aluminum plate
Body material:FRP+Color steel plate
Inside material: Color steel plate
Wire:4mm²
Stabilizer legs:AL-KO brand
Jockey wheels:500kg
Power Inlet :100~380V
Water inlet : Tap water or water tank
Tail light :E4 taillights
Standard Description:
Standard description:
1.Exterior material: FRP+Color steel plate.
2.Interior material: white color steel plate.
3.Outside configuration: tow bar with coupling, power inlet connector, service window, folding table,side window, tail lights system,any color painting,jacks
4.Inside configuration: led lights, electric system, anti-slip floor, breaker,working counter,wall shelf.
5.Customized color : any color available, you can choose color from www.ralcolor.com.
6.Customized size: length from 2.3m to 5.0m
7.Inside need customize, default inside no range hood, no any cooking equipment,no fridge etc
This food trailers/foodtrucks are customized, the price is the basic price, excluding equipment,shipping cost.
You can contact us to get the quotation.
